Matched spur gear set · 72T / 24T, 8 DP · Bliss #21 stamping press reduction
Custom-cut 4140 spur set to replace the reduction pair on a Bliss #21 press. 3:1 ratio, AGMA Q10.
- SKU
- MS-IP-0455
- Era
- 1950-2000
- Condition
- Custom-cut replacement pair, AGMA Q10, from certified 4140 stock. New from our shop.
- Dimensions
- 72T: 9.25" OD; 24T: 3.25" OD; both 3" face
- Weight
- 42 lb (pair)
- Provenance
- Miracle Supply Co. shop-cut. Pattern archived from a 1962 Bliss factory drawing set.
- Category
- Obsolete Industrial Parts
- Tags
- custom-gearspur-gearstamping-pressbliss4140-steel
A matched pair of spur gears cut in our own shop to replace the reduction pair on a Bliss #21 mechanical stamping press. 72 teeth and 24 teeth, 8 diametral pitch, 20-degree pressure angle, three-inch face — cut from certified 4140 pre-hard bar to AGMA Q10 tolerance.
The original Bliss factory pattern has been out of production since the E.W. Bliss consolidation in the late seventies. We reverse-engineered the geometry from a museum-condition original, verified against three service-worn examples, and now cut them on demand.
Bore and keyway are finish-machined to customer print. Lead time is stock if the profile matches; otherwise two to three weeks.
Related finds
More from Obsolete Industrial Parts →
Sand-cast phosphor-bronze worm gear from a Draper X-3 loom, 40 teeth, 20 diametral pitch, imperial bore.
